Product Information
A high security, heavy duty hasp and staple for sheds, gates and doors in heavy domestic, commercial and agricultural applications. The vertical pattern fixing plate makes this ideal for fitting to a narrow stile door or frame. Bolt fixed for additional security. Fixings included.
Documents
Technical Specifications
Product Specification
| Carriage Bolt Size mm | M12 x 75 |
| Fixing Plate Size L x W mm | 50 x 150 |
| Hasp Plate Size L x W mm | 92 x 55 |
| Nut Size mm | M12 |
| Size inch | 6 |
| Size mm | 150 |
| Staple Plate Size L x W mm | 65 x 55 |
| Washer Size mm | M12 |
| Corrosion Rating | 4 - Urban & industrial areas with a moderate salt atmosphere |
| CSK Screw Size mm | 5.0 x 30 |
| Max Padlock Shackle Diameter mm | 15 |
| No of Nuts | 2 |
| No of CSK Screws | 8 |
| No of Carriage Bolts | 2 |
| No of Washers | 2 |
| Pack Dimensions L x W x H mm | 20 x 160 x 290 |
| Pack Weight kg | 0.84 |
| Carton Qty Packs | 8 |
| Pallet Qty Packs | N/A |
| Product Code | VHS6GP |
| SKU Barcode | 5055893367056 |
| To Fit Carriage Bolt Dia mm | M12 |
| No of Bolt Holes | 2 |
Product Specifications
| Finish | Hot Dipped Galvanised |
| Material | Carbon Steel |
| Nut Type | Hex Full |
| Included Items | M12 x 75mm Carriage Bolts (Qty 2), M12 Hex Full Nuts (Qty 2), M12 Washers (Qty 2), 4.0 x 30mm Countersunk Screws (Qty 8) |
Attribute Group 1
| Brand | TIMCO |
Vertical Pattern Bolt On Hasp & Staple - Heavy Duty - Hot Dipped Galvanised
6"
- Product Code: VHS6GP
- Pack Type: TIMbag
- Pack Quantity: 1
- Barcode: 5055893367056
