Product Information
Manufactured from a high quality M35 grade steel. Ideal for drilling holes into stainless steel and other alloy materials. The 135° split point prevents the bit from drifting and enables faster penetration.
Documents
Technical Specifications
Product Specifications
| Material | M35 Alloyed HSS Steel with 5% Cobalt |
| Substrates | Plastic, Steel, Aluminium, Non-Ferrous Metals, Stainless Steel |
| Contents | 1.0 x 34mm (Qty 1), 1.5 x 40mm (Qty 1), 2.0 x 49mm (Qty 1), 2.5 x 57mm (Qty 1), 3.0 x 61mm (Qty 1), 3.5 x 70mm (Qty 1), 4.0 x 75mm (Qty 1), 4.5 x 80mm (Qty 1), 5.0 x 86mm (Qty 1), 5.5 x 93mm (Qty 1), 6.0 x 93mm (Qty 1), 6.5 x 101mm (Qty 1), 7.0 x 109mm (Qty 1), 7.5 x 109mm (Qty 1), 8.0 x 117mm (Qty 1), 8.5 x 117mm (Qty 1), 9.0 x 125mm (Qty 1), 9.5 x 125mm (Qty 1), 10.0 x 133mm (Qty 1), 10.5 x 133mm (Qty 1), 11.0 x 142mm (Qty 1), 11.5 x 142mm (Qty 1), 12.0 x 151mm (Qty 1), 12.5 x 151mm (Qty 1), 13.0 x 151mm (Qty 1) |
Product Specification
| Shank Type | Straight |
| Pack Dimensions L x W x H mm | 198 x 114 x 54 |
| Pack Weight kg | 1.42 |
| Carton Qty Packs | 10 |
| Pallet Qty Packs | N/A |
| DIN Standard | DIN 338 |
| Product Code | HSSCO25DS |
| SKU Barcode | 5055017542659 |
| Drill Dia mm | 1.0 - 13.0 |
Attribute Group 1
| Brand | TIMCO |
Ground Jobber Drills Set - Cobalt M35
25pcs
- Product Code: HSSCO25DS
- Pack Type: Case
- Pack Quantity: 25
- Barcode: 5055017542659
