Product Information
Carriage Bolt & Hex Nut - BZP
- Manufactured from grade 4.8 carbon steel
Documents
Technical Specifications
Attribute Group 1
| Brand | TIMCO |
Product Specification
| Nut Size mm | M10 |
| Nut Socket Size mm | 17 |
| Nut Type | Hex Full |
| Pack Dimensions L x W x H mm | 180 x 92 x 122 |
| Pack Weight kg | 3.88 |
| Pallet Qty Packs | 192 |
| Point Type | B Point |
| Product Code | 1030CB |
| Carton Qty Packs | 6 |
| CE Standard Web | BS EN 14592:2008 |
| Corrosion Rating | 1 - Clean, dry & low humidity environments |
| DIN Standard | DIN 603; DIN 934 |
| Finish | Zinc |
| Head Dia mm | 24 |
| Head Type | Dome |
| Included Items | M10 Hex Full Nuts |
| Inner Thread Dia mm | 9.8 |
| Length mm | 30 |
| Material | Carbon Steel |
| Material Grade | 4.8 |
| Screw Holes 6.0mm | WebAttribute |
| Size mm | M10 x 30 |
| SKU Barcode | 5055331802613 |
| Substrates | Hardwood; Softwood |
| Thread Coverage | Fully Threaded |
| Thread Dia mm | M10 |
| Thread Pitch mm | 1.5 |
| Thread Type | Metric |
Carriage Bolts & Hex Nuts - Zinc
M10 x 30
- Product Code: 1030CB
- Pack Type: Box
- Pack Quantity: 100
- Barcode: 5055331802613
